 MACH8, MACH8IOPS, MACH8MLC SOLID STATE DRIVES
STEC MACH8 Solid State Drive is revolutionizing the storage world by delivering to the users the ultimate level of reliability and performance in a fully integrated device.

At the heart of the MACH8 Solid State Drive there is STEC's leading edge controller able to address multiple flash chips simultaneously to achieve up to 100MB/s sustainable Read/Write speed.

The MACH8 product is embedding the Full Data Path Protection, STEC's proprietary set of algorithms capable to protecting the data wherever they are temporary or permanently stored.

 FEATURES
MACH8IOPS 5-Year Warranty (see warranty terms)
MACH8MLC 3-Year Warranty (see warranty terms)
MACH8 3-Year Warranty (see warranty terms)
Industriy leading Solid State Disk
Patented Full Data Path Protection
Low power consumption
Non-volatile memory and no moving parts
Two Operating Temperature supported:
  • Commercial Temperature: 0 to 70C
  • Industrial Temperature: -40C to 85C
Drop-in replacement for traditional 1.8”, 2.5” and 3.5” drives
Support Serial ATA and Parallel ATA
Sustainable Sequential Read and Write speed up to 100MB/s
Optional MACH8IOPS version for IOPS hungry applications
 SPECIFICATIONS
SPECIFICATION MACH8IOPS 2.5"
  INTERFACE
Serial ATA
  CAPACITIES
25GB - 100GB
  READ/WRITE PERFORMANCE
100MB/s
  ENVIRONMENTAL
  Commercial Temperature

0 to 70C
  POWER CONSUMPTION
  Idle
  Active

500mW
2.1W
SPECIFICATION MACH8 1.8" MACH8 2.5"
  INTERFACE
Parallel ATA/Serial ATA
Parallel ATA/Serial ATA
  CAPACITIES
32GB - 64GB
32GB - 256GB
  READ/WRITE PERFORMANCE
100MB/s
100MB/s
  ENVIRONMENTAL
  Commercial Temperature
  Industrial Temperature

0 to 70C
-40C to 85C

0 to 70C
-40C to 85C
  POWER CONSUMPTION
  Idle
  Active

500mW
2.1W

500mW
2.1W
SPECIFICATION MACH8MLC 1.8" MACH8MLC 2.5"
  INTERFACE
Parallel ATA/Serial ATA
Parallel ATA/Serial ATA
  CAPACITIES
64GB - 128GB
128GB - 512GB
  READ/WRITE PERFORMANCE
90MB/s, 60MB/s
90MB/s, 60MB/s
  ENVIRONMENTAL
  Commercial Temperature

0 to 70C

0 to 70C
  POWER CONSUMPTION
  Idle
  Active

500mW
2.1W

500mW
2.1W
 EDUCATION CENTER
 WHY MACH8?

Show All | Hide All
Performance
Full Data Path Protection
Power Down Protection
Extraordinary Environmental Specification
Low Power Consumption
S.M.A.R.T
Bill of Material Control

PERFORMANCE
MACH8 Solid State Drive

No matter how you measure performance, the MACH8 Solid State Drive will outperform the expectations.

The MACH8 Solid State Drive can achieve up to 100MB/s sustainable sequential read and write speed.

The Drive can deliver up to 5,000 read IOPS in the base version and up to 10,000 in the MACH8IOPS Solid State Drive version, 20 to 40 times more than the best HDD available on the market.

All these extraordinary performance are achievable thanks to the revolutionary architecture of the MACH8, designed for speed and reliability.

FULL DATA PATH PROTECTION
MACH8 Solid State Drive

Any data that is transferred to the drive is protected via a powerful Error Correction mechanism.

For the first time in the industry, the Error Correction is also applied to the cache memory and to the spare area of the flash, the critical area that stores the mapping information.

The MTBF of the MACH8 Solid State Drive is 2,800,000 hours, twice as much as the best-in-class HDD.

The non-recoverable error rate is less than 1 error per 1020 bits read.

POWER DOWN PROTECTION
MACH8 Solid State Drive

The MACH8 Solid State Drive employs both hardware and software mechanisms to prevent data loss in case of power fluctuation or power loss. The Hardware protection prolongs power long enough to transfer all the data from the cache to the non-volatile memory. The software protection assures data integrity by verifying that valid data are not overwritten by corrupted data.

EXTRAORDINARY ENVIRONMENTAL SPECIFICATIONS
MACH8 Solid State Drive

Given that there are no moving parts and thanks to the optimized sub-system design, the MACH8 Solid State Drive can withstand extreme environmental conditions.

The drive will survive Random Vibrations up to 16.3G and Operating Shocks up to 1,500G.

As any STEC's flash products, the MACH8 Solid State Drive is available also in Industrial Temperature Range (-40;85C), with non-operating temperature ranging from -55C up to 95C.

Relative humidity can ranges from 5% up to 95% and altitude goes from 1,000ft (-304.80m) up to 80,000ft (24,384m).

LOW POWER CONSUMPTION
MACH8 Solid State Drive

MACH8 Solid State Drive consumes only 2.1W in operating mode, roughly half of high-end rotating HDD. The same consideration applies for the idle state, with MACH8 consuming only 550mA.

S.M.A.R.T
MACH8 Solid State Drive

The MACH8 Solid State Drive supports the S.M.A.R.T. feature (Self-Monitoring, Analysis and Reporting Technology).

The S.M.A.R.T. feature set protects the user from unscheduled downtime by monitoring and storing critical drive performance and calibration parameters.

No unscheduled down-time is drastically reducing the total cost of ownership.

BILL OF MATERIAL CONTROL
MACH8 Solid State Drive

STEC provides complete Bill of Material control to assure to our customers that any product delivered matches completely the specification.

STEC also offers value-added services like customized form factors, testing, custom firmware, software imaging, customer-specific labeling and serialization.



IN THIS SECTION
Summary
Features
Specifications
Why MACH8?
Print Product Flyer
Share Product Flyer
DOWNLOAD CENTER
BROCHURES
MACH8 SSD Brochure
SSD Overview Brochure
RELATED DOCUMENTS
SSD Part Number Decoder
EDUCATION CENTER
WHY MACH8?
Performance
Full Data Path Protection
Power Down Protection
Extraordinary Environmental Specification
Lower Power Consumption
S.M.A.R.T
Bill of Material Control
PART NUMBERS
1.8" MACH8 SATA: 1.8" MACH8 PATA:
M8SB1-xxxUC M8AA1-xxxU(C/I)

2.5" IOPS SATA 2.5" MACH8 PATA:
M8(I)S(i)2-xxxU(C/I) M8(I)AA2-xxxU(C/I)

3.5" IOPS SATA: 3.5" IOPS PATA:
M8(I)S(i)3-xxxU(C/I) M8(I)AA3-xxxU(C/I)

1.8" MLC SATA: 1.8" MLC PATA:

M8SB1-xxxUCM

M8AA1-xxxUCM


2.5" MLC SATA: 2.5" MLC PATA:

M8SB2-xxxUCM

M8AA2-xxxUCM


GUIDE
M8:
  Family
A:
  Parallel ATA
S:
  Serial ATA
i:
  Interface Revision
1:
  1.8"
2:
  2.5"
3:
  3.5"
xxx:
  up to 256GB
U:
  RoHS-6 compliant
I:
  Industrial temperature
C:
  Commercial Temperature
